Description
End cap with integrated lip-seal for horizontal output DN/OD 110 in polymer concrete, for channels ACO MONOBLOCK RD100V.Total length 40 mm, external width 275 mm and height overall 160 mm. Weight: 2,6 kg.
Technical Specifications
Dimensions
- Material:
- polymer concrete
- Weight (kg):
- 2,6
- Length (mm):
- 40
- Width (mm):
- 160
- Height (mm):
- 275-100
- Output:
- DN/OD 110
