Description
End cap with integrated lip-seal for horizontal output DN/OD 160 in polymer concrete, for channels ACO MONOBLOCK RD200V.Total length 70 mm, external width 530 mm and height overall 260 mm. Weight: 13,1 kg.
Technical Specifications
Dimensions
- Material:
- polymer concrete
- Weight (kg):
- 13,1
- Length (mm):
- 70
- Width (mm):
- 260
- Height (mm):
- 530-200
- Output:
- DN/OD 160
