CNL ML V150S 5.0 100CM H235 E600

Surface drainage channel type ACO MULTILINE V150G 5.0 H235 in polymer concrete without grating. Load class till E600 in accordance with EN1433. Fast locking grates sytem by ACO Drainlock® over galvanised edge rails integrated on channel body wall. Internal area of 208 cm² with V-shape optimized transverse section. Total length 1000 mm, height overall 235 mm and total width 185 mm. Nominal width 150 mm. Weight: 31,3 kg.
